TT Technologies drill pipe
HDD Gear IEU-forged drill pipe for TT Technologies Grundodrill® HDD machines, covering the Grundodrill 4X through the 18N–28N range.
Grundodrill Series
TT Technologies Grundodrill® drill pipe
IEU-forged drill pipe matched to the Grundodrill machine families and their thread connections.
| Compatible machine | Part number | Body O.D. | Tool joint O.D. | Length | Weight (lbs) | Thread | Max torque (ft·lbs) | Bend radius / pipe | Bend radius (ft) | Pipes / box | Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Grundodrill 4X | DP-TT4X | 1.500″ | 1.900″ | 5′ | 23 | #200 | 950 | 0.051 | 98′ | 32 | |
| Grundodrill 18N-20N-28N | DP-TD82 | 3.62″ | 3.62″ | 10′ | – | TD82 | – | – | – | – |
Grundodrill® is a trademark of TT Technologies, Inc. HDD Gear pipe is compatible, not OEM. A dash (–) indicates a value not listed for that pipe.
Need Grundodrill pipe?
Send us your machine model and quantity and we'll come back with a quote and lead time.
